Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power

Nome da marca:	Yuchai engine
Número do modelo:	MB-1000
MOQ:	1 unidade
preço:	Price:Negotiable
Condições de pagamento:	Western Union, T/T, D/P, L/C.
Capacidade de abastecimento:	200 unidades/mês

Informações pormenorizadas

Descrição do produto

Informações pormenorizadas

Lugar de origem:

China

Certificação:

ISO 9001:14000,CE,EACC

Marca::

Gerador diesel de YUCHAI

Tensão nominal::

230V/400V

Modelo do motor::

YC6TF1520-D31

Corrente nominal::

1800A

Freqüência::

50Hz/60Hz

Marca do alternador::

MBKL / WUXI STANDFORD / STAMFORD / LEROY-SOMER

Painel de controle::

Deepsea / Harsen / Smartgen

Certificado::

ISO 9001: 14000, ce

ATS::

Opcional

Entrega::

7-30 dias

Tempo de garantia::

1 ano ou 1000 horas de execução (o que chegar primeiro)

Velocidade::

1500 rpm/1800 rpm

Detalhes da embalagem:

Plástico envolto em portadores de madeira como requisitos do consumidor. LCL, 20 pés e 40 pés estão

Habilidade da fonte:

200 unidades/mês

Descrição do produto

Yuchai YC6TF1520-D31 diesel generator sets features:

(1) . Full control panel with power indicator light and oil light.
(2). Emergency shutdown for low oil pressure and high water temperature.
(3). Large fuel tank ensure continuous running.
(4). Low noise & vibration.
(5). Compact structure.
(6). Reliable performance.
(7). Easy for installation and maintenance.

Painting materials
rust removing in pickling tank(10minutes)------unoil(30mins)-----rinsing(3mins)----wathsetting(10mins)----rinsing(5mins)-----parkerising(20mins)----rinsing----blow dry-----stoving----pylons----spray paint(adopt static flame paint)-----Oven(170degree/20mins)-----draw a charge---inserting coil.

Genset
Model	MB-1000
Output Power	1000KW/1250KVA
Power Factor	COSΦ=0.8( lagging)
Maximum Output Current	1800A
Silent type Weight	9150 kg
Silent type Dimensions	580024002900
Voltage	400/230V
Frequency	50Hz
Diesel Engine
Manufacturer	Yuchai Diesel Engine
Model	YC6TF1520-D31
Rotate Speed	1500RPM
Power	1118 kW
Fuel Consumption	≤195 g/kw.h
Lubricating oil capacity	95L
Cylinder/Stroke	152mm/200mm
Compression Ratio	13.5:1
Displacement	31.75L
Configuration	6-cylinder In-line, four-stroke, water-to-air cooling
Cooling Mode	Liquid Cooled
Speed Control System	Electronic
Starting Mode	24V DC
Filter System	Dry air filter, fuel filter, oil filter
Alternator
Manufacturer	Changsha Mingbang Intelligent Technology Co.Ltd
Model	MBV6F
Voltage Control Mode	AVR (automatic voltage regulation)
Voltage Regulation	±1%
Rated Voltage/Frequency/Power Factors	400V/230V, 50Hz, COSΦ=0.8 lagging, three-phase four-wire
Steady State Frequency	Better than 5%
No-load Voltage Adjust Range	≥95% - 105%
Insulation Class/Protection Class	H / IP22
Excitation Type	Brushless

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power 0

Our factory

Mingbang Power Perkins Diesel Generating Set, power ranging from 45kVa up to 2250kVa. Perkins is the world's top engine brand, for more than 80 years, UK Perkins has been the world's leading supplier of diesel and gas engines in the 4 - 1800 kW market. Perkins key strength is its ability to tailor engines precisely to meet customers' requirements, which is why its engine solutions are trusted by more than 1,000 leading manufacturers in the industrial, construction, agricultural, materials handling and electrical power generation markets.

Our factory has CCEC, DCEC, PERKINS,MTU,Deutz, Daewoo, SDEC, Weichai,Jichai etc. World and Chinese famous engine for generators set. We have specialized in synchronous 100%copper wire alternator for more than 20 years. MB brand alternator has been expanded all over the world. The power range of our generator is from 6.5KW~2000KW.

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power 3

New Powered By Yangdong Engine Prime Power 800kw Diesel Generator Set

Industrial 1000kW Silent Generator Set with Yuchai Engine for Reliable Backup Power 4

More details for diesel generator sets ,please contact us any time

Your further inquiry will be welcome!!
